HAMMERFIX COUNTERSUNK WHITE PAINTED 5X35MM 200PCS

Package information

Item no. 304708
Package PC
PackageType ESSBOX 204
Content 200
Ordered in multiples of 1
EAN 7317761012269
NOBB nr 21659024
Pallet quantity 480
Depth 180
Width 90
Height 80
Weight 0.648
Volume 1.296

ESSVE HF Nail Plug is designed for easier installation of battens, skirting, linings, fittings, cabinets and the like in materials such as concrete,solid brick, natural stone and hollow core slab.

A special ribbed nail, pre-fitted in a plug. The plug has a short expansion section for solid homogeneous materials described above. The plug is manufactured of nylon.

For dimension 10 mm the plug and nails are supplied separated in the pack and the plug must first be pushed into the hole and then the nail is knocked in. The nail head has a Pozidriv-cross. The nail plug can then be easily removedSee the installation instructions at the end of this section.

Technical Specification

Anchoring depth 20
Application environment Indoors
Color White
Head shape Countersunk
Corrosion resistance class C1
Diameter [mm] 5
Drill bit diameter 5
Drill depth 40
Length 35
Fixture thickness 15
Material to install in Concrete, Brick, Stone
Minimum anchorage depth 20
Standard anchoring depth concrete 20
Surface treatment Zinc plated
Type of bits PZ2
Type of collar Countersunk
